CMSC 110 (Introduction to Computing)

Fall 2012

Assignment #6

Due by 10:00 am on Wednesday November 28, 2012

For this assignment, you can choose between two options.  Choose and complete ONE of them.

Option 1:  Image Collage

Task: Write a Processing program that generates a collage of images.

The collage should be created by applying image processing techniques to draw modified copies of the same image (or same set of images) at multiple locations on your sketch window. At least four distinct modifications of the source image(s) should be used to create your collage.

For example, you may load your source image four times into separate PImage objects and then modify the colors of one to create distinct appearance, i.e. creating Warhol-esque variations, or draw each pixel as a square of a certain size with colors from the original image. Each modified PImage can then be drawn multiple times on your sketch at various locations, rotations and sizes to form your collage.

Step 1: Create at least 4 processed images (as PImage) from the original, using distinct image processing techniques.  Example PImage modifications include:

• Simple Filters - pixel color is set depending on its own color
• mapping to grayscale, sepia, negative
• modifying brightness, contrast, color and transparency
• check out Processing's tint() for alternatives
• Pixel math - pixel color is set as a weighted average of itself and another (from another image)
• Add/subtract images
• Blend images
• check out Processing's blend() for alternatives
• Area-based filters - pixel color is set depending on the neighbors
• highpass filter - sharpen areas with rapid intensity changes (sharpen)
• lowpass filter - blur areas with rapid intensity changes (blur)
• noise removal
• Dilation/erosion - morphological operation expanding/shrinking bright regions
• Image segmentation - pixel color is set depending on some threshold (note that those listed here also use filtering techiniques, simple color filters for posterizeing and area-based filters for edge detection and feature extraction typically, so they technically belong to more than one categories)
• thresholding color values - posterize, histogram, etc
• check out processing's filter() for alternatives
• edge detection
• feature extraction - lines, edges, ridges, blobs, faces, etc
• Image visualization
• pointillism
• other representations such as letters, symbols, shapes, fragments of other images etc

You are highly encouraged to checkout the tutorials on Image Processing on www.processing.org, which can be found here: http://processing.org/learning/pixels

Step 2: Create a collage from the set of processed images you generated in step 1.

• Copy, resize, crop and sample the images at will to create fragments. Useful functions:
• img.get(x, y, width, height) - returns a rectangular region of the PImage img starting at (x, y), with the specified width and height
• Arrange the fragments in your sketch window to create a meaningful composite. Use transformations liberally. Useful functions:
• translate()
• rotate()
• scale()
• pushMatrix()
• popMatrix()
• image()
• imageMode()

Image Filtering Requirements:

1. All modifications must be performed on the individual pixels of the original PImage.
2. You may not use existing Processing image processing functions like filter(), tint(), and blend().
3. Among the required 4 images to create, you must implement at least one technique from "Image visualization" and one from "Area-based filters". Any one that fits the category will do, it does not have to be one that is listed.
4. The other two (or more) can be your choice.

Recursion Requirement:
Your sketch must contain at least one usage of recursion.  Recall that a function is recursive if it calls itself.  The manner in which you use recursion is completely up to you.  However, here are a couple of examples to help you brainstorm.  One possibility is to use recursion when displaying the individual images of your image collage (see first three examples below).  Another possibility is that one of your image filters may be recursive (for instance in the fourth example below).

Above: an example of a recursive image collage	Above: an example of a recursive image collage	Above: an example of a recursive image collage	Above: an example of a recursive image filter

What to hand in:

• Any images you use - this is important as your program won't work without the original images!
• These must be placed properly in the data folder of your sketch.

• Make absolutely certain that your program isn't referring to images located elsewhere on your computer.

• Include a screen shot of your collage - using the save() function from Processing may be easier.
• Copy your entire sketch folder into your Dropbox folder.

• Make sure to name the sketch file/folder properly.
• Put your paragraph/description and the header in your source code file.
• Comment your code liberally with meaningful descriptions.

Option 2:  Photomosaic

Task: Write a Processing program that generates a photomosaic for a given picture.

A photomosaic depicts an image by a collection of smaller tiled images.  The first step in creating a photomosaic is to have a library of images that will form the tiles. The photomosaic is then created by breaking the original photograph into super-pixels (small rectangular regions that cover multiple pixels in the original image), and then substituting in small photos that closely approximate each super-pixel from the library.  Imagine that we are using a super-pixel that is 20 x 20 pixels, effectively a square grid of 400 colors.  The first step is to divide the original image into non-overlapping super-pixels.  For each of these super-pixels, we then take an average of the red, green, and blue values for each of those 400 underlying pixels, giving us a single RGB triple to represent that super-pixel.  Then, we find the closest matching photo from the library (taking the average RGB values across the entirety of each photo in the library), resize it to be 20 x 20 pixels, and substitute it in place of the super-pixel in the original image.

To start, choose about a dozen images of varying colors and textures for your library of tiles.  Save these images to your data folder under your sketch.  Try to cover as many different colors as possible.  I strongly recommend using an image editing program to resize these images down to about 50 pixels by 50 pixels.  The exact size doesn't matter; the only reason we are reducing the size using an image editor is to make the file sizes small.

These are the steps your program should take to generate the photomosaic:

Step 1:  Load these images into Processing as an array of PImage objects.  Choose a tile size; this must be a variable so that it can be easily changed to generate different resolution photomosaics.

Step 2:  For each image in the library, resize it to be the same as the tile size and compute the average red, green, and blue value for that photo.  You may want to make a simple class to hold both this average color and the original PImage, or you can maintain two arrays (one of average colors and one of PImages -- just make sure that the i^th color corresponds to the i^th image).

Step 3:  Load the original picture that you will turn into a photomosaic.  Your program should have a single String variable specifying the filename of the original picture.  That way, you can easily change the filename to load a different picture and generate a new photomosaic.

Step 4:  Divide the original picture into super-pixel regions, and compute the RGB color for each super-pixel.

Step 5:  For each super-pixel, determine the tile image in the library that is most similar by measuring the Euclidean distance between their RGB triples.  For example, let (r1,g1,b1) be the RGB color triple for the super-pixel of the original image, and let (r2,g2,b2) be the RGB color triple for a tile image.  The Euclidean distance between their RGB triples is then measured dist(r1,g1,b1,r2,g2,b2).  The most similar tile image is the one with the closest distance.

Step 6:  Once you have found the closest tile to each super-pixel, draw those tile images in place of the super-pixels.  At this point, you should have a working photomosaic program.

• To simulate different shades and increase the diversity of your library, you may want to duplicate some images in the library and apply different filters to those images to change their colors.  Make some images darker, some images brighter, etc.  All this should, of course, be done programmatically in Processing -- not using an external image editor.

• In this current version, each tile image and super-pixel is summarized by a single average RGB color.  Instead of measuring the distance between these two averages, you could measure the sum of the distances between each pixel in the super-pixel and each pixel in the tile image (provided that the tile images are all resized to be the same size as the super-pixel).   Then, the closest tile image is the one with the lowest sum of distances.  This will allow your program to better choose the tile image for each super-pixel.  Experiment with different measures of distance to see what works best.

• Incorporate recursion into your program, either by defining a recursive filter or by generating a recursive photomosaic!  (see Option 1 for a few examples of recursive images)


• Any images you use - this is important as your program won't work without the original images!
• These must be placed properly in the data folder of your sketch.

• Make absolutely certain that your program isn't referring to images located elsewhere on your computer.

• Include a screen shot of your photomosaic - using the save() function from Processing may be easier.
• Copy your entire sketch folder into your Dropbox folder.

• Make sure to name the sketch file/folder properly.
• Put your paragraph/description and the header in your source code file.
• Comment your code liberally with meaningful descriptions.
